Product Details:
Place of Origin: | kiosk manufacturer |
Brand Name: | Lien |
Certification: | FCC, CE, ROHS |
Model Number: | LKS-8379 |
Payment & Shipping Terms:
Minimum Order Quantity: | 10 UNITS |
---|---|
Price: | $ |
Packaging Details: | Strong Case |
Delivery Time: | 5-6 weeks |
Payment Terms: | TT |
Supply Ability: | 5000 units per month |
The Touch Screen kiosks Self Service Checkout with Bar-code Scanner is an advanced self-checkout system that combines touch screen operation and barcode scanning capabilities. The system is widely used in retail stores, supermarkets, convenience stores and other commercial environments. Through the touch screen interface, customers can easily scan products, select payment methods and checkout processes, while barcode scanners ensure fast and accurate reading of product barcodes. This system not only improves checkout efficiency and reduces customer wait times, but also reduces reliance on human cashiers through automation, thereby optimizing store operation processes and customer shopping experience.
Components | Details | |
PC system | Industrial Board | Seavo/ Gigabyte/Advantech AIMB 562 |
CPU | Dual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7 | |
RAM | 2GB /4 GB / 8GB | |
HDD | 500G | |
Interface | 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card | |
Industrial Board | Seavo/ Gigabyte/Advantech AIMB 562 | |
LCD monitor | Screen Size | 32inch ( optional from 8inch to 65inch) |
Brightness | 250cd/m2 | |
angle | horizontal 100°above;Vertical 80°above | |
Contrast | 1000:1 | |
Backlight tube life | more than 40,000hours | |
Max. resolution | 1280×1024 | |
Touch screen | Screen Size | 32inch Diagonal ( optional from 8inch to 65inch) |
Resolution | 4096x4096 | |
High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times | ||
Bank/Credit Card Reader | Interface | RS232 |
Card Type | Support Magcard, IC Card, RF Card, Mifare S50,S70,UL Card | |
Power Voltage | DC 24V±5% | |
Card Entry method | Magnetic signal, Optoelectronic signal and rear card signal | |
Encrypted Pin-pad | Keylift~span | 2,000,000 cycles |
Key force | 2~3N | |
Key trip | >2.5mm | |
Protection level | ip65 | |
Cash code Bill acceptor | Validation Rate | 96% or higher |
Banknote Insertion | Four-way | |
Escrow | One banknote | |
Capacity | 1000 notes Max | |
Coin Acceptor | Coin Acceptance | Max 32 coin types, in 2*16 or 1*32 channels |
Detection ability of counterfeit Coins | with high detection ability of counterfeit coins | |
Accepting Speed | 2 Coins/Sec | |
Supply Voltage | 10V-16V DC | |
Epson receipt thermal printer | Auto cutter | included |
Technology | Thermal printing | |
Paper width | 80mm | |
Printing speed | 150mm/s | |
Data buffer | 4KB | |
Interface | RS232 ,USB | |
UPS | Input voltage | 145-290va |
Output voltage | 200-255va | |
Max time for supplying a single PC | 3~20minutes (for single PC) | |
Digital Power Supply | AC input voltage range | 100~240VAC |
Frequency | 50Hz to 60Hz | |
AC input voltage range | 100~240VAC | |
Frequency | 50Hz to 60Hz | |
Accessories | Accessories | Wire-lan port, USB ports, speakers, fans, cables, screws, etc. |
Operation System | Operation System | Windows 7 or Windows XP operation system without license or Android System |
KIOSK Cabinet | KIOSK Cabinet | Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Anti-rust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request. |
Packing | Packing | Security Packing method with bubble foam and wooden case |
1.LCD monitor
LCD monitor has become an important choice in modern display equipment because of its excellent image quality, energy saving and environmental protection characteristics and multi-functional design. Its high resolution and high contrast ensure that the image is clear and delicate, especially suitable for office, entertainment, design and other application scenarios. The thin design and lightness of the LCD monitor allow it to save space while providing a modern and beautiful appearance to adapt to the needs of different environments.
2.Credit Card Reader
A credit card reader is a device specifically designed to read and process credit card information and is widely used in a variety of transaction venues, including retail stores, dining establishments, financial institutions, and online payment platforms. By reading the magnetic strip or chip on the credit card, this device can quickly obtain the card number, cardholder name, and other important information to complete the payment verification and authorization process. Modern credit card readers not only support traditional magnetic stripe cards, but also read advanced EMV chip cards and contactless (NFC) cards, ensuring the security and convenience of the payment process.
The Touch Screen kiosks Self Service Checkout with Bar-code Scanner can be used in a variety of scenarios, retail stores, restaurants, movie theaters and other places to see this machine, by providing fast and convenient checkout methods, optimize the operation process in a variety of business environments, improve the customer experience, and help merchants improve operational efficiency.
1.The Touch Screen kiosks Self Service Checkout with Bar-code Scanner feature highly efficient barcode scanners that quickly and accurately identify items, significantly increasing checkout speeds and significantly reducing customer waiting times in line. The scanner is able to read product barcodes at extremely fast speeds, ensuring that each item's information is quickly entered into the system, avoiding the delay caused by manual entry errors or slow operations in the traditional checkout process.
2.Bar code scanner not only improves the accuracy of commodity information entry, but also ensures the timely update and management of inventory data through the integration with the inventory management system. This precise and efficient data processing helps optimize inventory control, improve the operational efficiency of merchants, and enhance the shopping experience for customers.
1.Choosing a barcode scanner with high scanning speed and accuracy is the key to checkout efficiency and customer satisfaction. These scanners can quickly and accurately read product barcodes and QR codes, greatly reducing customer waiting time. It is also crucial to ensure that the scanner can recognize various types of barcodes and QR codes. This compatibility allows the scanner to handle different kinds of goods, whether it is a traditional bar code, a complex QR code, or other special forms of coding, it can be accurately read.
2.When choosing a Touch Screen kiosks Self Service Checkout with Bar-code Scanner with barcode scanners, it is crucial to ensure that the device has strong data encryption and a tamper-proof design. These security features are essential to protect customers' payment information and personal data, preventing data breaches and fraud.
Q: Are you a manufacturing or trading company?
A: We are an OEM/ODM kiosk manufacturer
Q: How to ship the kiosk?
A: Air and sea shipping are optional, and sea shipping is recommended for bulk orders. All kiosks should be shipped in a standing position and must not be put down.
Q: What payment methods does your company accept?
A: We accept most payment methods, but mainly accept T/T. L/C, Western Union, PayPal and Money Gram.
Q: How long is your delivery time?
A: It depends on the order quantity, about 5 weeks for samples and about 4 weeks for less than 100 units.
Q: What is the warranty period of your kiosk?
A: 12 months from the date of shipment, for components, free repair or replacement, shipped by sender.
Q: Can you customize the kiosk?
A: Yes, we always customize the product according to your requirements. Including redesigning the kiosk appearance, printing your company logo, choosing specific colors, etc. OEM or ODM is available.
Q: What is the MOQ?
A: The MOQ is 1 unit, we accept samples
