Self-Service Health Kiosk Machine Floor Standing Self Service Hospital Kiosk Machine With Rfid Card Reader

Product Details:

Place of Origin: kiosk manufacturer
Brand Name: Lien
Certification: FCC, CE, ROHS
Model Number: LKS-8379

Payment & Shipping Terms:

Minimum Order Quantity: 10 UNITS
Price: $
Packaging Details: Strong Case
Delivery Time: 5-6 weeks
Payment Terms: TT
Supply Ability: 5000 units per month
Detailed Product Description

The Self-Service Health Kiosk Machine is a floor-standing self-service hospital terminal equipped with an RFID card reader, providing a one-stop self-service solution for patients and visitors. The device supports health card reading, information query, appointment management and other functions, with simple operation and intuitive user interface. Its RFID technology ensures the accuracy and security of data reading, significantly reduces the waiting time of patients in the hospital, optimizes the service process of medical institutions, and improves the overall service efficiency and user experience. This terminal is particularly suitable for multi-functional applications in modern medical environments.




Specification


ComponentsDetails
PC systemIndustrial BoardSeavo/ Gigabyte/Advantech AIMB 562
CPUDual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7
RAM2GB /4 GB / 8GB
HDD500G
Interface6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card
PC Power SupplyHUNTKEY/Great Wall
LCD monitorScreen Size17 inch/19inch ( optional from 8inch to 65inch)
Brightness250cd/m2
anglehorizontal 100°above;Vertical 80°above
Contrast1000:1
Backlight tube lifemore than 40,000hours
Max. resolution1280×1024
Touch screenScreen Size17/19 inch Diagonal ( optional from 8inch to 65inch)
Resolution4096x4096
High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times
Bank/Credit Card ReaderInterfaceRS232
Card TypeSupport Magcard, IC Card, RF Card, Mifare S50,S70,UL Card
Power VoltageDC 24V±5%
Card Entry methodMagnetic signal, Optoelectronic signal and rear card signal
Encrypted PinpadKeylift~span2,000,000 cycles
Key force2~3N
Key trip>2.5mm
Protection levelip65
Epson receipt thermal printerAutocutterincluded
TechnologyThermal printing
Paper width80mm
Printing speed150mm/s
Data buffer4KB
InterfaceRS232 ,USB
UPSInput voltage145-290va
Output voltage200-255va
Max time for supplying a single PC3~20minutes (for single PC)
Digital Power SupplyAC input voltage range100~240VAC
Frequency50Hz to 60Hz
AC input voltage range100~240VAC
Frequency50Hz to 60Hz
AccessoriesWire-lan port, USB ports, speakers, fans, cables, screws, etc.
Operation SystemWindows 7 or Windows XP operation system without license
KIOSK CabinetDurable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request.
PackingSecurity Packing method with bubble foam and wooden case



1000-图-L型_画板 1.jpg


Feature:

1.Thermal printer

2.Passport reader

3.Barcode scanner

4.Coin dispenser

5.Cash acceptor

6.RFID card reader

7.Web camera


Benefit:

1. Improved accessibility: Essential medicines and health products are available 24/7, making it convenient for customers to get what they need at any time, especially outside normal pharmacy hours.

2. Convenient and fast: Allowing customers to quickly purchase medicines without queuing, reducing waiting time and enhancing the shopping experience.

3. Multiple payment methods: Supporting multiple payment methods, including POS and cash QR code payment, meets the preferences of different customers and ensures a seamless transaction process.

4. Hygienic transactions: Using contactless payment methods minimizes physical contact, promotes hygiene and safety, which is particularly important during public health issues such as epidemics

5. Spatial efficiency: The compact design of the self-service terminal makes it suitable for placement in a variety of locations, including hospitals, shopping malls and transportation hubs, thereby maximizing space utilization.

6. Reduced operating costs: The automated sales of over-the-counter drugs and products reduces the need for additional personnel, thereby saving costs for the business.

7. Real-time inventory management: The self-service terminal is able to monitor inventory levels in real time, ensuring that products are always available, helping to maintain optimal inventory levels and reduce out-of-stocks.


FAQs


1.Q: What are the main components of the kiosk hardware?

A: The main components include a touchscreen, card reader, receipt printer, QR code scanner, and sometimes a camera or biometric scanner.



2.Q: What maintenance does the hardware require?

A: Regular maintenance includes cleaning the screen and components, checking for software updates, and ensuring that all hardware parts are functioning properly.



3.Q: What should I do if the hardware is not working properly?

A: If the hardware is not working properly, try restarting the kiosk. If the problem persists, contact technical support for assistance.



4.Q: Does the kiosk hardware require specific environmental conditions?

A: The kiosk should be placed in a temperature-controlled environment, away from direct sunlight, and protected from moisture and dust.



5.Q: Can the kiosk hardware accept different types of payments?

A: Yes, the kiosk can accept a variety of payment methods, including credit/debit cards, mobile payments, and sometimes cash, depending on the model.
