Product Details:
| Place of Origin: | kiosk manufacturer |
| Brand Name: | Lien |
| Certification: | FCC, CE, ROHS |
| Model Number: | LKS-8379 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 UNITS |
|---|---|
| Price: | $ |
| Packaging Details: | Strong Case |
| Delivery Time: | 5-6 weeks |
| Payment Terms: | TT |
| Supply Ability: | 5000 units per month |
The 32inch Self-Service Checkout Kiosk With Bar-code Scanner , POS Terminal And Loyalty Card Reader are common devices in the retail industry, providing customers with a contactless, fast and convenient self-checkout experience.Customers can easily scan items, complete checkout and pay without the assistance of a shop assistant. These kiosks are simple and intuitive in design, easy to operate, and very friendly to customers of all ages. This contactless self-service has become an important development trend in the retail industry, greatly improving checkout efficiency and optimizing the shopping experience.
Components | Details | |
PC system | Industrial Board | Seavo/ Gigabyte/Advantech AIMB 562 |
CPU | Dual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7 | |
RAM | 2GB /4 GB / 8GB | |
HDD | 500G | |
Interface | 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card | |
Industrial Board | Seavo/ Gigabyte/Advantech AIMB 562 | |
LCD monitor | Screen Size | 32inch ( optional from 8inch to 65inch) |
Brightness | 250cd/m2 | |
angle | horizontal 100°above;Vertical 80°above | |
Contrast | 1000:1 | |
Backlight tube life | more than 40,000hours | |
Max. resolution | 1280×1024 | |
Touch screen | Screen Size | 32inch Diagonal ( optional from 8inch to 65inch) |
Resolution | 4096x4096 | |
High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times | ||
Bank/Credit Card Reader | Interface | RS232 |
Card Type | Support Magcard, IC Card, RF Card, Mifare S50,S70,UL Card | |
Power Voltage | DC 24V±5% | |
Card Entry method | Magnetic signal, Optoelectronic signal and rear card signal | |
Encrypted Pin-pad | Keylift~span | 2,000,000 cycles |
Key force | 2~3N | |
Key trip | >2.5mm | |
Protection level | ip65 | |
Cash code Bill acceptor | Validation Rate | 96% or higher |
Banknote Insertion | Four-way | |
Escrow | One banknote | |
Capacity | 1000 notes Max | |
Coin Acceptor | Coin Acceptance | Max 32 coin types, in 2*16 or 1*32 channels |
Detection ability of counterfeit Coins | with high detection ability of counterfeit coins | |
Accepting Speed | 2 Coins/Sec | |
Supply Voltage | 10V-16V DC | |
Epson receipt thermal printer | Auto cutter | included |
Technology | Thermal printing | |
Paper width | 80mm | |
Printing speed | 150mm/s | |
Data buffer | 4KB | |
Interface | RS232 ,USB | |
UPS | Input voltage | 145-290va |
Output voltage | 200-255va | |
Max time for supplying a single PC | 3~20minutes (for single PC) | |
Digital Power Supply | AC input voltage range | 100~240VAC |
Frequency | 50Hz to 60Hz | |
AC input voltage range | 100~240VAC | |
Frequency | 50Hz to 60Hz | |
Accessories | Accessories | Wire-lan port, USB ports, speakers, fans, cables, screws, etc. |
Operation System | Operation System | Windows 7 or Windows XP operation system without license or Android System |
KIOSK Cabinet | KIOSK Cabinet | Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Anti-rust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request. |
Packing | Packing | Security Packing method with bubble foam and wooden case |
1.The 32inch Self-Service Checkout Kiosk provides a clear, detailed display of product information, making it easy for customers to view and confirm shopping lists and checkout information.The 32-inch Self Service Checkout Kiosk is an efficient and convenient self-checkout device common in modern retail, providing a comfortable shopping experience and improving checkout efficiency.
2.Barcode scanners mainly use the principle of optical imaging to quickly and accurately read the information on goods, documents or any object with a barcode or two-dimensional code. It can greatly improve the speed and accuracy of data entry, and is widely used in retail, logistics, inventory management and other fields.
3.POS Terminal is an electronic device that integrates sales, management and data analysis. It is widely used in various business scenarios to help merchants improve efficiency and customer satisfaction.
1.Retail malls: In large supermarkets, shopping centers or department stores, 32-inch Self Service Checkout kiosks are often placed in a prominent position to facilitate self-service checkout and reduce the burden of manual checkout counters.
2.Transportation hubs such as airports and train stations: In these places, travelers often need to complete shopping and checkout quickly. The fast Checkout function of the 32-inch Self Service Checkout Kiosk is designed to meet travelers' quick shopping needs.
3.Catering industry: In fast food restaurants, cafeterias and other catering places, self-checkout kiosks can provide customers with a more convenient self-service checkout experience, but also reduce the pressure of service staff.
1.Providing customers with a contactless, fast and convenient self-checkout experience.
2.Customers can easily scan items, complete checkout and pay without the assistance of a shop assistant.
1.Features and performance: Select a self-checkout kiosk with the right features and performance for your needs. In addition to basic scanning, checkout, and payment functions, consider integrating other functions such as loyalty card readers, coupon printing, and more.
2.User friendliness: Consider the user friendliness of self-checkout kiosks. Choose devices that are simple in design and easy to operate to ensure that customers can easily use and enjoy a convenient shopping experience.
3.After-sales service and support: Understand the supplier's after-sales service and support before purchase. A good supplier should be able to provide equipment installation, commissioning, maintenance and technical support and other comprehensive services.
Q: Are you a manufacturing or trading company?
A: We are an OEM/ODM kiosk manufacturer
Q: How to ship the kiosk?
A: Air and sea shipping are optional, and sea shipping is recommended for bulk orders. All kiosks should be shipped in a standing position and must not be put down.
Q: What payment methods does your company accept?
A: We accept most payment methods, but mainly accept T/T. L/C, Western Union, PayPal and Money Gram.
Q: How long is your delivery time?
A: It depends on the order quantity, about 5 weeks for samples and about 4 weeks for less than 100 units.
Q: What is the warranty period of your kiosk?
A: 12 months from the date of shipment, for components, free repair or replacement, shipped by sender.
Q: Can you customize the kiosk?
A: Yes, we always customize the product according to your requirements. Including redesigning the kiosk appearance, printing your company logo, choosing specific colors, etc. OEM or ODM is available.
Q: What is the MOQ?
A: The MOQ is 1 unit, we accept samples
