Shenzhen Lean Kiosk Systems CO., LTD
Product Details
| Place of Origin: | kiosk manufacturer |
|---|---|
| Brand Name: | Lien |
| Certification: | FCC, CE, ROHS |
| Model Number: | LKS-8379 |
Payment & Shipping Terms
| Min Order: | 10 UNITS |
|---|---|
| Price: | $ |
| Packaging: | Strong Case |
| Delivery Time: | 5-6 weeks |
| Payment Terms: | TT |
| Supply Ability: | 5000 units per month |
Detailed Product Description
The Shopping Center Kiosk Tablet Machine with Payment is a self-service terminal specifically designed for shopping malls that integrates advanced payment functions to significantly improve customer convenience and merchant operational efficiency. This self-service terminal not only simplifies the shopping and payment process, but also provides customers with a smooth and efficient shopping experience, while helping merchants optimize management and increase sales.
Components | Details | |
PC system | Industrial Board | Seavo/ Gigabyte/Advantech AIMB 562 |
CPU | Intel Dual Core G2020 | |
RAM | 2 GB | |
HDD | 500G | |
Interface | 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/1000M Net Port ;Integrated Net Card, Sound Card | |
PC Power Supply | HUNTKEY/Great Wall | |
LCD monitor | Screen Size | 22 / 17 inch ( optional from 8inch to 65inch) |
Brightness | 250cd/m2 | |
angle | horizontal 100°above;Vertical 80°above | |
Contrast | 1000:1 | |
Backlight tube life | more than 40,000hours | |
Max. resolution | 1280×1024 | |
Touch screen | Screen Size | inch Diagonal ( optional from 8inch to 65inch) |
Resolution | 4096x4096 | |
High Transparent, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times | ||
Receipt / Ticket Printer | Interface | High Speed USB |
Resolution | 4800*1200 maximum | |
Printing speed | 4.8 ipm | |
Width | 58 /80 /112 mm | |
Length | Customizable | |
| Resolution | 1280*720 |
Pixel | 8000000 | |
Adaptive Resolution | 1280*720 | |
Interface | USB 2.0 | |
Driver | No | |
NFC card reader | Status Display | LED indicator to show the power or communication status |
Card Type | ISO14443TypeA of Contact-less IC Card, including Mifare S50,Mifare S70,MF1ICL10,Mifare Pro,Mifare desfire,Mifare ultralight | |
Type | Support ISO14443 | |
2D scanner | Readable Code | CMOS |
Resolution | 752*480 | |
Readable Code | 2D PDF417, QR Code(Model 1/2), Data Matrix(ECC200, ECC000, 050, 080, 100,140), Aztec, Maxi-code, etc ;1D Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ISBN, Code 93, UCC/EAN-128, GS1 Data-bar, etc | |
Approval | FCC Part15 Class B, CE EMC Class B | |
Work Voltage | DC 5V (4.5-5.5V) | |
Interface | RS232, USB | |
Wireless module | WLAN module | With industrious antenna exposure |
Motorized card reader | Card type | Support Mag card, IC Card, RF Card, Mi-fare S50,S70,UL Card |
Magnetic Head Life | 500,000/min | |
IC Card Touch Port | 300,000/min | |
Speakers | Features | Dual channel amplified speakers for Stereo ,8Ω 5W |
Digital Power Supply | AC input voltage range | 100~240VAC |
Frequency | 50Hz to 60Hz | |
AC input voltage range | 100~240VAC | |
Frequency | 50Hz to 60Hz | |
Accessories | Wire-lan port, USB ports, speakers, fans, cables, screws, etc. | |
Operation System | Windows 7 or Windows XP operation system without license | |
Free standing Cabinet | Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Anti-rust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request. | |
Package | Security Packing method with bubble foam and wooden case | |
1.Touch screen tablet
Equipped with a high-definition, high-resolution touch screen, it provides an intuitive and user-friendly interface that makes it easy for customers to browse and select products. The touch screen supports multi-touch technology and is responsive, ensuring that customers can operate smoothly during use, whether they are browsing menus, viewing product details or completing payments, they can get a great interactive experience.
2.Self-service function
Customers can easily place a self-service order by browsing the product or service to see details and prices. The system provides a shopping cart management function, allowing customers to add, modify or delete items, and confirm before placing orders to ensure accuracy. This process simplifies the purchasing experience for customers, enabling them to complete the entire shopping process easily and quickly.
3.Integrated payment features:
It supports a variety of payment methods, including credit and debit cards and mobile payments (such as Apple Pay, Google Wallet), providing customers with flexible and convenient choices. The system has built-in secure payment processing functions to ensure transaction security and data privacy, protecting customers' personal information and payment data.
1.Shopping centers: Provide self-service shopping and payment solutions for various stores in shopping centers to improve the overall quality of service.
2.Food and beverage service: Installed in restaurants or fast food restaurants to provide self-service ordering and payment functions to improve service efficiency and enhance customer satisfaction.
3.Retail stores: Deploy in retail stores to streamline customers' shopping and checkout processes and optimize the overall shopping experience.
1.Improve customer experience
Self-service terminals enable customers to complete their own shopping and payment, thereby reducing queuing time and significantly improving shopping efficiency. By offering a variety of convenient payment methods, such as credit and debit cards and mobile payments (e.g. Apple Pay, Google Wallet), customers can choose the most appropriate payment method according to their preferences. In addition, the user-friendly interface design is intuitive and easy to use, enabling customers to easily browse products, view details and complete purchases, improving the overall convenience and satisfaction of shopping. These features work together to ensure that customers enjoy a smooth, efficient and enjoyable experience during the shopping process.
2.Optimize operational efficiency
Automated order processing reduces manual operations, not only reducing labor costs, but also significantly reducing error rates. The system's real-time data update and order management functions enhance the overall operational efficiency of merchants and make inventory management more accurate and efficient. These optimization measures enable merchants to better coordinate resources, respond to market demand, and improve the overall level of business operation.
1.Technical support
After-sales service: Understand the comprehensive technical support and after-sales service provided by the supplier, including system maintenance, troubleshooting and software updates and upgrades. Ensure that suppliers have the ability to respond quickly so that problems can be solved in time to ensure the stable operation of the system.
Training support: Ensure that suppliers provide adequate training resources to help employees quickly master the operation and functions of the system. Including detailed training manuals, online training courses and on-site training, etc., to ensure that all employees can proficiently use the system, improve work efficiency and service quality.
2.Cost assessment
Total cost : When evaluating the system, the initial purchase cost, the installation cost, and the long-term maintenance cost should be fully considered. Initial purchase costs include the purchase of hardware and software, while installation costs cover the cost of system deployment and configuration. Long-term maintenance costs include system maintenance, updating and support costs. Make sure these expenses are within your budget and bring real value to your business.
Cost Performance : Evaluate whether the functionality and benefits of the system match its cost. Consider whether the capabilities provided by the system meet your business needs, improve operational efficiency, optimize the customer experience, and deliver significant returns. Choose cost-effective solutions that minimize costs and ensure a return on investment while ensuring system performance and functionality.
Q: How to ship the kiosk?
A: Air and sea shipping are optional, and sea shipping is recommended for bulk orders. All kiosks should be shipped in a standing position and must not be put down.
Q: Are you a manufacturing or trading company?
A: We are an OEM/ODM kiosk manufacturer
Q: What payment methods does your company accept?
A: We accept most payment methods, but mainly accept T/T. L/C, Western Union, PayPal and Money Gram.
Q: How long is your delivery time?
A: It depends on the order quantity, about 5 weeks for samples and about 4 weeks for less than 100 units.
Q: What is the warranty period of your kiosk?
A: 12 months from the date of shipment, for components, free repair or replacement, shipped by sender.
Q: Can you customize the kiosk?
A: Yes, we always customize the product according to your requirements. Including redesigning the kiosk appearance, printing your company logo, choosing specific colors, etc. OEM or ODM is available.
Q: What is the MOQ?
A: The MOQ is 1 unit, we accept samples
